TS8022L SPDT 50W/125Wpeak RF GaN Switch

Active

Features

Frequency Range 30MHz to 6.0GHz

Low insertion loss:

    • 0.30dB @ 2.0GHz
    • 0.55dB @ 4.0GHz
    • 0.65dB @ 6.0GHz, matched

High isolation:

    • 32dB @ 2.0GHz
    • 20dB @ 4.0GHz
    • 19dB @ 6.0GHz

50W CW Power, 125Wp Peak Power

Low power consumption, less than 1mW

Switching time 5.2us

P0.1dB compression point 50dBm

H2, Pin=45dBm, 800MHz, -86dBc

H3, Pin=45dBm, 800MHz, -89dBc

Functional diagram
4.0 x 4.0 mm2 QFN package
Datasheet
S-parameters
EDA model (bxl)
Evaluation kit

Buy from
TagoreTech inc.

support@tagoretech.com

Precision Tech Advice.
Local Expertise


Chesapeake

Shop our distributors

Buy EVB

Digikey

RFPD

graph in preparation
graph in preparation
Insertion Loss and Return Loss, no matching elements
Isolation Antenna/RF-port to non-active RF-port
